Recently I posted a video on You Tube explaining why I like to use the Nik Plugin’s from Photoshop rather than Lightroom. This came about because in all my Nik videos I start with a RAW file in Lightroom This is then converted to an image that I edit in Photoshop. A couple of people asked why and so I recorded the video for You Tube.
The video has been very well received but given it’s only had a few hundred views. To ensure everyone has access to the information I decided to also post this blog. Whilst I am referring to the Nik Collection in the video, the same argument applies to most filters.
The problem I have when using a plug-in for Lightroom is that you can end up creating lots of new files. This can be hard to manage and quickly becomes messy. If you are working on a RAW file you have no option but to convert the RAW file to an image before editing it with (what Lightroom calls) an external editor. This creates a new file, duplicating the original RAW file with adjustments.
After you have edited your image, you may need to apply a second filter to the image. When this happens, you have the option to work on either another copy of the image file or apply the adjustments to the image you created previously. The first option creates yet more image files. The second provides no “back-out” in case you make a mistake; you would need to start again from the RAW file.
Photoshop is better option as each adjustment filter can be applied as a new layer. The Nik Collection even has a setting you can use to automatically.
Once you are working with layers in Photoshop, other options are available to you:
- You can reduce the opacity of the layer if you find the effect you applied is too strong.
- You can use layer masks to hide or reveal areas of adjustment in the image. For example, you might like the sky in the adjusted image but not the rest. You could use a layer mask to hide the adjustment but then paint back the adjusted sky. You can even create quite complex masks using luminosity and channel mask techniques.
- Perhaps the biggest advantage is that you can convert layers in Photoshop to Smart Objects. When you apply a Nik filter to a Smart Object, all the settings you apply in Nik are saved, including control points. This means when you save your finished image as a PSD file, you can open and adjust the settings in your Nik filter, even moving control points.
If some of this doesn’t make sense, watch the video below. If you want to know more about the Nik workflow, look at my book “Nik Efex from Start to Finish”.
Yet another week over and we are rapidly approaching Christmas. Then it’s soon going to be New Year and I will be beating myself up that I haven’t achieved half of the things that I wanted to with this blog and my website (Lenscraft). When I select the image above to share I thought that I had shot it recently. Now that I look back I realise it was from the 5th November. It seems like yesterday but it’s a month and a half ago.
The image was captured using a Fuji XT2 and the excellent Fuji 16-55 lens. The camera was tripod mounted as the lens, despite being excellent lacks any stabilisation. Despite shooting at ISO 200 I used f/10 to ensure full depth of field. I probably didn’t need to use such a small aperture but I’m really feeling my way with the APSC sized sensor at present. Had I been shooting with the Olympus EM5 I would have been using f/7.1 and been confident of front to back sharpness. The EM5’s smaller Micro 43 sensor makes the increased depth of field at wider apertures possible.
In addition to the above equipment I was also using a Lee 0.3 (one stop) ND Graduated filter to hold the exposure in the clouds. The other filter used was a 105mm polarising filter which screws to the front of the Lee 100mm filter system.
When it comes to post processing, I have recorded the entire thing and posted it as a video on YouTube. Here is the link in case your reading this as an email.
If you’re on the lightweightphotographer website, you will see the video embedded below. I hope you enjoy this and have a great weekend.
I have now been shooting with the Fuji X-T2 for a couple of months. Whilst I have only had a few outings, I’m very pleased with the results. I like the handling of the camera and also the lens quality despite a couple of problems. In fact, the 10-24 and 16-55 lenses are nothing short of exceptional.
There is though one problem that has niggled me for a while and this is the “Wiggly Worm” pattern. You tend to find this in areas of fine detail when converting RAW files using Lightroom or Adobe Camera RAW. This is a real shame, especially as I use Lightroom for much of my cataloguing and image management.
To illustrate the problem, a look at the image below which has been magnified at 2:1 in Lightroom; you may need to double click the image to open it at full resolution (I was also running my Mac at 2048 x 1152 when I took the screen shots so this will magnify the image further).
I can easily avoid the problem by switching to Iridient Developer or RAW Therapee but I like working in Lightroom. I have therefore been looking at how to reduce the “Wiggly Worm” effect and I think I have hit on something.
I had originally put the effect down to the demosaic routine that converts the RAW file. But I have changed my mind and now think it’s the sharpening routine that creating much of the problem. The example I showed above was created using the default Lightroom Radius setting of 1, an Amount setting of 45, a Detail setting of 75 and Threshold of 10. The culprits that seem to exaggerate the problem are the Amount and Masking sliders.
Masking causes the sharpening effect to be concentrated onto the edges in the image. Only when the Masking is set to 0 is the entire image sharpened. The “Wiggly Worm” effect seems to be created when the edges in areas of fine detail become exaggerated. Effectively the edges are becoming over sharpened, which is why the Amount slider has such an impact on the result. You only need to increase it slightly and the effect is emphasised. The Detail slider has less of an effect because it sharpens only very high frequency details.
So, what does this mean and how can you use it?
Limit the sharpening applied in Lightroom. Here is the same example but sharpened using much less aggressive settings.
This used the settings or Radius = 0.8, Amount = 30, Detail = 30 and Masking = 0. The image is a little softer but much more natural.
Following this approach, I have found I can minimise the “Wiggle Worm” effect whilst producing images with greater detail. Although the images coming from Lightroom are slightly softer, they respond so much better to additional capture sharpening using Nik RAW Sharpener or Photoshop Smart Sharpen. You can see a further example here viewed at 100% magnification.
You may now be wondering why bother with Lightroom capture sharpening at all and simply apply Capture Sharpening in another tool. Well, I tried this and to my eyes at least, a small amount of Capture Sharpening in Lightroom seems to produce better results when sharpened a second time outside Lightroom.
But does all this pixel peeping matter? My answer to this question is yes and no.
If you are going to be displaying your image on the internet, then you will most likely be down sampling them. The act of down sampling will remove some of the “Wiggly Worm” effect and can even remove it completely depending on how much you reduce the image size. If you are going to be printing the image, the softening effect of printing will also remove the pattern. For these reasons, I say that it doesn’t matter.
Where this effect does cause a problem, is if you are submitting your images to others for inspection. A typical example might be when you submit images to a stock library for sale. Here they probably will pick up on the pattern and might well reject the images.
I have seen many articles and videos over the years suggesting ways to create infrared simulations using regular colour photographs. Most of these fall short, possibly because the authors don’t appreciate the true characteristics of infrared. One example I read simply suggested using the channel mixer in Photoshop and using it to turn a blue sky black.
The best tool I have seen for simulating the effects of Infrared film a standard colour image is Alien Skin Exposure. This is also one of the tools I turn to when converting my digital infrared images as it allows me to simulate the halation effect often seen with Kodak HIE film. Unfortunately, as great a tool as Exposure is, it’s costly.
So how can we create a simulation using Nik plug-ins? Well, there is an Infrared film simulation in Nik Color Efex Pro but it’s not very convincing and doesn’t produce the halation effect. Nik Silver Efex Pro did once have an optional preset you could download from the Nik website but this has been removed. In any case, the preset wasn’t very believable.
This video features my simple solution based on combining a couple of filters in Nik Color Efex with a monochrome conversion in Silver Efex Pro. It’s quick to do and is quite effective.
[If your reading this as an email you won’t see the video. Please visit the YouTube channel link below to view.]
If you like the video why not subscribe to my You Tube channel and be sure not to miss future videos. Use the link below to access the channel then click the subscribe button in the top right.
Have you ever wanted to tweak the camera profiles in Lightroom? Or perhaps you have wondered how Camera Profiles are created? Perhaps you don’t like the profiles that ship with your camera and want to create something better.
This short video introduces you to a great free tool from Adobe that allows you to generate new, bespoke camera profiles and install these to Lightroom. I demonstrate the process using RAW files from a Fuji X-T2 but you can apply this to any camera which shoots RAW. Just watch the video, download the software and in 5 minutes you will have created your own profile.
If I had to take a guess, I suspect 98% of you reading this will never have seen this technique before. Don’t miss out.
[This post includes an embedded video. If you are reading this as an email you will need to visit my blog]
If you have a You Tube account and want to subscribe to my channel you can access it with the link below. Just click on the subscribe button in the upper right of the screen.
My latest video is now live on You Tube. You can subscribe to my channel using the link below
or watch the video here (please note the video doesn’t show up in email, only on the blog).
If you’re a Lightroom user and aren’t familiar with changing your Camera Profile, be sure to watch this. There is a second part to this video which is coming soon and I doubt many people will have seen anything like it before.
The image you see above is the RAW file used in the video once it’s been fully processed.
You asked to see how it was done. Here is the video to explain. This shows how you can achieve quite dramatic black and white conversions using only Lightroom. You don’t need any other software or filters. What limits you is your imagination.
I hope you find this video useful and don’t forget to subscribe to my You Tube channel if you haven’t already.
