Another Example of False Infrared Colour

Posted on Updated on


GX1 Infrared image converted with a red blue channel swap to create a false colour
GX1 Infrared image converted with a red blue channel swap to create a false colour

In my last post I shared an example of the false infrared colour technique and explained how it was achieved. I also confessed that in general I don’t like the effect, although in some cases it does work well. I thought it would be good to share another example that I think works reasonably well (although not as well as the previous post)  although I will admit that I still prefer the traditional black and white conversion.

This example is a little more stylised than the previous image and was created by first converting the image to colour before applying a Fuji Provia Slide Film simulation in Exposure 6. This was then further edited with a boost to the Vibrancy slider and a negative Clarity to give the soft effect. My reasoning for these adjustments was to prepare the image for conversion to black and white but I found I quite liked the colour image.

When converting the images with the Channel Mixer it can seem a bit hit and miss. It appears to help if you have both sky and foliage in the image. With a Red/Blue channel swap such as shown here the sky will turn blue and the foliage will go red. Most other areas (in landscapes) tend not to be affected.

You can improve the results by picking a white balance point during RAW conversion which causes the foliage to take on a blue tint. Typically this will leave the sky with some red tint and when the channel swap is made with the channel mixer the red tint in the sky turns blue and the blue tint of the foliage turns red.

Also try to avoid images which have been shot in the shade (such as tree lined country lanes) as you won’t get such a good effect. You really need direct and strong sun to make this work well.

Hope this helps anyone who is also struggling with Infrared false colour.

Infrared conversion from my GX1 Infrared camera
Infrared conversion from my GX1 Infrared camera

False Colour Conversion in Infrared Photography

Posted on


False colour infrared using Infrared converted Panasonic GX1
False colour infrared using Infrared converted Panasonic GX1

Before I get into the details of this post I need to point out that I’m not a fan of the false colour effect in infrared. That said I do quite like the look of the image above. I realise this is a personal choice and you may or may not like the effect. Despite not liking this effect (other than the odd image) I continue to use the technique as I find it often helps in the conversions to black and white. The increased colour seems to make it easier to separate objects in black and white .

The starting point for the conversion is an infrared image that has been correctly white balanced. You can see the starting point below.

Correct white balance
Correct white balance

As I have mentioned previously in this blog, getting the white balance correct in Lightroom and Adobe Camera RAW can be problematic. Here is an example of the image as seen in Lightroom despite using the correct custom white balance.

How Lightroom sees the custom white balance
How Lightroom sees the custom white balance

I have now found out how to correct this and will post something separately on the subject.

Once you have your image white balanced, take it into Photoshop. Here we will do something called a channel swap between the red and blue channels using the Channel Mixer. You can see a screenshot of the channel mixer below.

Channel Mixer in Photoshop
Channel Mixer in Photoshop

In case you are wondering there isn’t a cannel mixer in Lightroom or Elements.

First select the Red channel in the channel mixer. You will notice the red slider is at 100% and the other two sliders are at 0%. Change these sliders so that the blue channel is at 100% and the others are at 0%.

Now repeat this process selecting the blue channel. This time set the blue slider to 0% and the red slider to 100%. The channel swap is now complete and you will see an effect similar to that above.

You can also swap any two channels and are not restricted to the red and blue. The red and blue channels tend to produce the best results though.

Now as I mentioned at the start of this post, I use this technique to support conversion to black and white. With that in mind, here is the final image back and white image. Let me know which image you prefer.

Final infrared conversion
Final infrared conversion

How did it look at the start?

Posted on Updated on


An interesting conversion using Nik Silver Efex Pro 2
An interesting conversion using Nik Silver Efex Pro 2

After I posted this black and white image taken from near the summit of Great Gable in the English Lake District a number of you wanted to know what the starting image looked like. Well here is it.



Starting image prior to processing in Nik Silver Efex Pro 2
Starting image prior to processing in Nik Silver Efex Pro 2

Looks great eh and you can immediately see how I turned it into the finished version above (only joking). If you can’t and want to know how I achieved the conversion, take yourself over to my Lenscraft website and register as a member – don’t worry it’s free. This entire conversion will be detailed in Summer 14 newsletter which I will be publishing shortly. Members receive an email notification when the newsletters published. You can also be sure that I won’t spam you as I HATE spam email.

Friday Image No.015

Posted on


Olympus EM5. Ambleside, The Lake District.
Olympus EM5. Ambleside, The Lake District.

I have been so busy this past week that I hadn’t realised Friday had come round again. Then I realised that I didn’t have an image to share so I started to look back over my shots from last year. A lot of the folders I have done nothing with. Despite this there are a few images that show some promise but which I overlooked at the time.

Here’s one example shot at dawn at the Marina in Ambleside. The weather didn’t play out quite as we had hoped for and the bank of heavy cloud failed to clear. It’s still quite a pleasant image though.

Have a great weekend.

Friday image No.011

Posted on Updated on


Reflections on my walk - Sony RX10
Reflections on my walk – Sony RX10

I love reflections., I find them fascinating and beautiful whether created on manmade surfaces or in nature. I suppose the ones we find in nature are the ones that really enthral me and I can’t help reaching for my camera.

Here is one from my walk last weekend in Jumbles Country park near to Bolton. I just printed this and my immediate thought was that it has a lovely soft quality to it. It was shot on an RX10 which is an easy take anywhere camera. Such a shame it’s so expensive and twice the size of the Olympus EM5.

Have a great weekend.

Friday image No.008

Posted on


Wonderful morning light. Captured using an Olympus EM5 and Olympus 9-18mm lens (my favourite lens for landscape work).
Wonderful morning light. Captured using an Olympus EM5 and Olympus 9-18mm lens (my favourite lens for landscape work).

Another image from my recent Yorkshire Dales trip. This was also taken on the first morning and is perhaps my favourite image from that day. I feel the quality of light is amazingly strong in this image. The light quality is often better in the morning than the evening as there is less dust in the atmosphere. This gives the light a sharp and clean feel. The heavy rain storms the night before also helped a lot. It’s this feeling of clean, sharp yet warm light that I find so captivating – the locations not bad either.

Have a great weekend.

Friday image No. 007

Posted on Updated on


Twistleton Scar, Ingleton, The Yorkshire Dales. Captured on an Olympus OMD EM5
Twistleton Scar, Ingleton, The Yorkshire Dales. Captured on an Olympus OMD EM5

Nothing too much to describe here.

This is Twistleton Scar in the Yorkshire Dales and was photographed last weekend. I love the location and it’s not often I can get to it for dawn. I really need some time to perfect the processing of the image but I hope you like this early version.

Friday Image 006

Posted on


Mountains of Norway. Captured on a Panasonic GF1 with Panasonic 45-200 lens.
Mountains of Norway. Captured on a Panasonic GF1 with Panasonic 45-200 lens.

In all my dashing around today I almost forgot to post my Friday image. I quite like the discipline of trying to create and post an image a week. I know others seem to manage one or more a day but I have too much else on to be able to make such a commitment. I think creating 1 image a week that I am happy to share is a good goal.

I shot this one almost 2 years ago on a trip to Norway. This was shot from the Hertigruten boat (I think it was the Troll Fjord). These provide a ferry service around the coast although it’s quite a bit more luxurious that this suggests. I think this was somewhere before we reached the Lofoten Islands. I came across the image whilst starting to clear out some of my many images and took a few minutes (about an hour really) to process it.

It was captured on a Panasonic GF1 with a Panasonic 45-200mm lens.

Have a great weekend.

Lightweight Panoramic Set-up

Posted on


120 degree panoramic stitch from 7 files shot on an OMD
120 degree panoramic stitch from 7 files shot on an OMD. Click to view larger.

Not too long ago I related how I had been struggling with the small size of my Olympus OMD EM5 when using it on a tripod. My solution to this had been to buy the two part grip and also to use an L-bracket from Novoflex. The Novoflex bracket wasn’t required to solve the size issue but was the solution to another problem of how to shoot stitched panoramic images with the camera positioned vertically. If you didn’t read the original blog you can find it here.

What I didn’t say in the original article is that I had even considering buying a Nikon D800E together with some lenses. Not a decision I would take lightly, as I am after all the Lightweight Photographer. I therefore decided to try an extended period of working with the Olympus on a tripod. This weekend past I had my opportunity to do just that. Here is what I found.

Firstly I need to share my decision. I won’t be buying the Nikon or any other DSLR for that matter. The OMD EM5 was a joy to work with on tripod using my new setup. Despite the Nikon D800E being a wonderful camera, there are some aspects to the camera that make me think it’s a backward step.

The new found size of the Olympus with the grip attached made it perfect for tripod work. Not only that, I found it very easy to work with and the L-bracket was perfect for quickly shifting the camera to a vertical orientation. If you are interested in shooting panoramic images but don’t yet have a head, then I really recommend you get one of these

Finally, I want to reveal my new panoramic set up for single row shooting and stitching.

New Panoramic set up
New Panoramic set up

As you can see, this uses my Novoflex L-bracket attached by the Novoflex Q-Mount plate. The Q-mount has then been attached to a Macro focus rack which is used to move the camera for focussing in macro work. Instead, here it allows me to position the camera lens on the nodal point so that I can easily create a stitch.

The cost of this setup – Novoflex L-bracket £69, Q-Mount £49, Focus Rack £7.30 – yes less £8 from Amazon (here is the link). I will also reveal that I have an even cheaper option for an L-bracket which is only £20, but I am waiting for that to arrive before I get peoples hopes up.

So, does it work? Yes it does and is much easier to work with than my larger and heavier panoramic head. I was able to carry this set up around all day (10 miles on day 1 and 8 miles on day 2). The only difficulty I had is in finding the nodal point. I needed to have worked this out prior to venturing out but because the focus rack only arrived when I was leaving the house I couldn’t and needed to guess instead. Trial and error seems to suggest the Nodal point for the micro 43 lenses is pretty much at the front element but that might not always be true. Once I have some time I will work it out properly and can then use the scale on the bracket and rack to find it quickly in the field.

As for the image above, this comprises 7 vertical shots using the 14-45mm lens at 14mm. It also swings through about 120 degrees. When stitched it gives a 17” x 54” print at 300dpi. If I drop the resolution to 250dpi and resize the image slightly then I believe a 35” high panoramic will be possible even if you press your nose to the image.

The stitching aspect of this image was done using Photoshop CS5 and there was very little distortion. I now need to spend some time working with Hugin to see what is possible as I took quite a few sequences with ultra wide angle lenses, as well as having the camera angled down.

The OMD EM5 has superb image quality and this set up allows me to make the most of it.

Free Soft Proofing Article

Posted on


The vivid colours of Artists Palette in Death Valley in the late evening sun. If you want to reproduce colours like these in print you will need to do some soft profile to ensure the image looks right. If you don't, it's going to be very hit and miss.
The vivid colours of Artists Palette in Death Valley in the late evening sun. If you want to reproduce colours like these in print you will need to do some soft profile to ensure the image looks right. If you don’t, it’s going to be very hit and miss.

I have just finished and uploaded an article on how to use the Soft Proofing features in Lightroom 4. You can download the article for free from my Lenscraft website by following this link to the Members Area. You will need to log in as a member to gain access but membership is free and you gain access to a lot of other articles and free information. Alternatively you could just wait until the article is publish on ePHOTOzine in the next few weeks.

Enjoy
