Free Lightroom Printing Article


Natural colours like these need special attention when printing. I have found Lightroom to be a particularly good solution.

Natural colours such as these found in the Artist Palette in Death Valley need special attention when printing. I have found Lightroom to be a particularly good solution. Click the image to see a larger version.

Last week was a big week for me. After 5 years of painfully slow service I decided to replace my PC. The PC in question is an old quad core HP with 1TB storage across 2 hard drives running Vista 64bit and 4GB of memory. It was state of the art 5 years ago but is now painfully slow. To give you some idea it takes 40 minutes to start up. My new PC starts in under 30 seconds running Windows 8. I also want to say that I now hate Microsoft with a vengeance for what they have done to the Windows operating system and the amount of time I am now wasting trying to find my way around.

Anyway, the point of this blog post is that it took me most of last week to migrate my computer data and install all my software to the new system. In all this activity I forgot to post that I had just added a new comprehensive article to the Members area of my Lenscraft website covering Printing in Lightroom. So if you are a Lightroom user you can download it for free by following this link – you do need to be signed in as a member but joining is also free.

Alternatively you can wait for it to be published on ePHOTOzine some time in the next few weeks.

Printing, Always an Interesting Exercise


Not taken with Lightweight gear but this is the colour image I was using to test my prints. It's quite challenging to print and shows up poor colours quite well.

Not taken with Lightweight gear but this is the colour image I was using to test my prints. It’s quite challenging to print and shows up poor colours quite well.

As I mentioned in one of my previous blog posts, I recently sold my printer, a Canon Pixma 9500MKII. The main driver for this was that I wanted to make larger prints, typically A2 or 17” wide panoramic. I also wanted larger ink cartridges because I do quite a lot of printing and I thought this might help reduce the overall cost. Well, my new printer arrived at the weekend, an Epson Pro3880 which is A2 and will print 17” panoramic up to 37” or wider if you use a third party RIP rather than the Epson print driver. Sounds great and it is, but there have been a few surprises.

First was a nice surprise in how small the printer was. It’s not much wider than the Canon (but it’s a little taller) and fits neatly at the side of my desk. I am also surprised about how little ink has been used in the 30 plus test prints I have made; this barely registers on the ink monitor. I had read reviews and comments by others about just how much ink is in these high capacity ink cartridges but I hadn’t really appreciated it until now. I’m sure however I will be crying when it comes to the cost of replacing just a single cartridge.

Now for a surprise I wasn’t prepared for; the Canon Pixma 9500MKII made nicer black and white prints (I didn’t check colour but suspect it was more vibrant). Before the Canon was sold, I made quite a few test prints on different papers (using high quality fine art and fibre based papers) in an attempt to pick a paper to standardise on. After this I started to use a Permajet paper called Fine Art Pearl 290. It wasn’t quite as good as Ilford Gold Fibre but the differences were so minor that most people wouldn’t spot them but it was excellent for both mono and colour work. As I still had a number of test packs available as well as paper I had purchased I decided to repeat the exercise and the results were very surprising:

As already mentioned, none of the papers could compete with the prints made on the Canon. This was despite producing custom profiles. Held side by side with the Canon the Epson prints looked a little flat where the Canon produced prints with a greater feel of depth.

All the papers tested with the Epson produced broadly similar results when printing in black and white. The main difference was the base colour of the paper. Some were warm tone whilst others were neutral and others still were bright white. The Ilford Gold was however better than the rest and was only marginally beaten by the Ilford Gold Mono.

Printing in colour revealed quite a variation between papers. The Ilford Gold again produced the best results with the other papers looking rather lifeless and flat. Only the Gold had a real depth to it.

This exercise was also repeated by another friend who has the same printer and his results are very similar. In a “blind” review of each other’s results (so we couldn’t be swayed by knowing the paper manufacturer), we came up with identical conclusions. We had to conclude that with the Epson the Ilford Gold was the best paper. This is a real shame because it’s a very expensive paper and the cost will tend to curtail the amount of printing I do.

The story doesn’t end there however because I decided to try out some Fotospeed PF Gloss 270. This is a standard gloss photographic inkjet paper that is around quarter of the price of the Ilford Gold and I didn’t expect it to be very good. Whilst I am not a fan of the Gloss surface I had to admit the results were almost as good as the Ilford Gold for Mono and marginally better for colour prints. This is quite a shock but makes printing much more affordable. I am now keen to try out the Satin or Lustre finishes to see if they are preferable to the gloss surface. If they are I think I will be buying this for my regular printing and saving the Fine Art Papers (Ilford Gold) for any print sales.

The downside to using standard photo papers for printing. They don’t feel as nice as the fine art papers to touch – not an issue when they are framed. They also don’t have quite as nice a surface finish – again this is hard to see if the work is framed and is probably my personal preference.

I hope this helps anyone out there struggling with cost and the difficult decision of which paper to print with.

Printer Paper Choice


Urban abstract shot on an LX5 and converted to B&W using Nik Silver Efex Pro. I love printing images like this but paper choice is critical to creating a great impact.

Urban abstract shot on an LX5 and converted to B&W using Nik Silver Efex Pro. I love printing images like this but paper choice is critical to creating a great impact.

If I go back about 10-15 years, photographers regularly had prints made and shared these with other photographers so that work could be discussed. The film you shot would also determine how you shared your work. If you shot B&W or Colour print film you might have small 7×5 prints made when your films were developed and perhaps you would have an enlargement made of anything that really impressed you. If you developed your own film (usually black and white) and had access to a dark room, you might make your own enlargements. In rare cases you might also have access to equipment to make your own colour enlargements. Finally, if you shot slide film you either looked at the slides on a lightbox or projected your slides. Having a print made from a slide was rare and expensive with few labs offering this service.

Then the inkjet printer came onto the scene and the quality and ease with which a print could be produced improved. This was further fuelled by a switch to digital by many photographers and now we most photographers could make A4 and often A3 prints. Strangely, despite this ease, many photographers seem to have dropped printing in recent years in favour of sharing their work on the Internet. To me, this is a real shame because something is lost from the creative process when you don’t make a physical print of your work. This is not because there is an extra creative step in the printing but because printing helps you really appreciate an image as often leads you to refine and improve it further.

When you hold an A4 or A3 print of your work you tend to assess it differently to how it is viewed on the screen. Part of this comes down to paper choice which can have a huge impact on the end result. For a start there are different paper surfaces such as Matt, Gloss, Lustre, Perl, Silk etc. Then there is the base for the paper as well as the colour of the print surface. There are so many creative choices that you can waste a huge amount of time and money searching for papers that suit the style of your work and your creative desire.

Unfortunately you don’t really appreciate all the different subtleties of the different papers until you print a lot. By this time you might have purchased lots of different papers only to find out that you don’t like them or that they can’t produce the depth of image that you desire. I know this because I have shelves full of different types of paper. Some of these were relatively cheap and almost without exception the cheap papers don’t give a feeling of depth to the printed image. Instead the image seems to just sit as a flat image on the surface of the paper. If I compare this with one of my favourite papers (Ilford Fibre Gold), the images seem to have a depth to them that would allow you to almost reach into the image with your arm; they feel almost three dimensional.

If I were to generalise, the papers from the main well known manufacturers (Canson, Hanimuhle, Ilford, Permajet, Fotospeed) seem to produce this feeling of depth. Many of these manufacturers produce standard photo papers and fine art papers and it is the fine art papers that tend to produce the better results. It’s then a matter of choosing a surface that suits your intention. I personally like the Fibre Based papers (they feel like a traditional dark room paper) with a silk semi-gloss finish and a neutral to warm tone base colour.

Of all the papers I have used, the Ilford Gold and Permajet Fibre Based Photo Art Perl 290 papers are my favourites by far. They are superb for both colour and black and white and suit all types of images.

Very recently Permajet released a new paper type called Titanium. This is a Metallic paper surface which is similar to the Kodak Metallic paper offered by some photo labs. I find this very interesting as I haven’t seen a Metallic paper for Inkjet printing before. Having used metallic paper with lab prints in the past I know that it will produce very vivid colours and deep Black and Whites. Place prints made with this type of paper in sunlight and they come to life in a way that other papers can’t. I was very keen therefore to try out some of this paper but the results are a little mixed.

The surface and colour are what could only be described as metallic in appearance. The colour is therefore quite a departure from what I usually work with and I can’t make up my mind it I like it or not. The colour prints are quite good but the paper seems to open up the shadows a little more than I would have liked and the colour intensity therefore suffers a little. I think this paper has a huge dynamic range and would suite colour HDR images quite well. In terms of black and white I can only describe the performance as superb. The images look as though they are standing off the paper. This again is quite different from my other papers where the image seems to go into the paper to give depth.

Would I recommend this paper?

Probably if you need the specific look it produces. I don’t think it’s a general, “suites everything” type of paper and therefore it won’t be replacing my Permajet Perl (which is my main paper of choice). I do however think it is worth experimenting with if you are a keen printer and want something a little different.

I hope you have found this little diversion into the world of printing interesting and that if you don’t already produce prints are encouraged to do so. We need to share our work as physical images not just as photons radiating from a screen.

Making Large LX5 Prints Again


This isn’t an image I have chosen to print large but it does help me appreciate how great the LX5 is. You should be able to make out a post on the horizon. If I zoom in to 200% on my monitor with the full resolution image I can make out a series of white depth marks on the post. The ability to resolve this much detail is simply amazing for such a small camera. By the way, the light rays are real.

It’s not often that I have free time these days but this weekend was different. My wife had gone to a knitting exhibition over in Harrogate with her sister and I found myself with a free afternoon. On the rare occasions when this happens and I don’t have any photography organised I like to experiment with photography software and image processing. This weekend was no exception and I decided I wanted to produce some large LX5 prints.

My target was to produce a 30” inch print which would stand close scrutiny.  Whilst a print of this size needs to have some distance between the image and the viewer to be appreciated, I also want to feel happy that if someone (probably me) sticks their nose up to the print, that it would still appear detailed and sharp. The image I went to work on was this picture of Brooklyn Bridge (shown below) that I shot last March on my LX5 whilst visiting New York.

LX5 image of the Brooklyn Bridge which I selected for printing at 30″ x 20″

When we prepare an image we usually think about our vision and how we can create this using either the camera or image manipulations such as dodging and burning. But if you are intending to print large you also need to evaluate the image to find and correct weaknesses that will become apparent in a larger print. The main areas of concern are noise, sharpness and detail.

The detail element of the image really needs to be addressed first during image capture. The best way to do this is to use good lenses, shoot in RAW and then expose to the right on the histogram (overexpose the image slightly). This moves a lot of areas out of the shadows and helps open them up to increase detail. Also the way image sensors work, a lot more information is captured in the darker areas with a lot less noise present. The result is a more detailed image which is sharper in the darker areas. The over exposure is then corrected when the RAW file is converted. As I always shoot in this way I had a good starting RAW file.

My next step was to assess the image for weaknesses. Here I could see some limited Luminance noise, especially in the clear blue sky. I decided that I needed to do a good job of selective noise reduction to focus on the shadows and on the sky. I did this using the Nik Define filter but I was careful to make my conversion from RAW with no sharpening and only colour noise reduction first. By not sharpening at all I ensured the noise was not emphasised before I applied the noise reduction. I also like to ensure the Nik Define filter is the first luminance noise reduction applied to the image as I have found this works best.

The steps above gave me a nice clean starting position to make my adjustments and convert to Black and White. After the Black and White conversion I used a programme called Topaz Detail which is very good at revealing details hidden in the image. Only once I was happy with this did I resize my image and then apply selective sharpening to the finished image. This gave me a nicely detailed and sharp image that was also very clean in terms of noise. Whilst I don’t yet have the print I can judge how it will look by viewing my image at 50% magnification.I have taken a screen grab of part of the 30inch x 20 inch image zoomed to 50% so you can judge this for yourself.

Captured on an LX5 and enlarged to 30″ x 20″. This section of the enlarged image is shown at 50% magnification to give an approximation of the detail in the final print.

I also produced a second resized image at 18” on the longest side in order to print on A3+ paper. The resulting print is very detailed, with nice tones and is exceedingly sharp.

I hope information helps you if you are seeking to make larger prints from an LX5 or similar quality compact.

You want to print it how big



I remember when I first purchased my Canon 5D MKII. One of the drivers behind this decision was to have a 21MPixel sensor. This was partly due to the main stock library I supplied only accepting 50Mb files and the pixel count on the 5D making this easy to achieve without interpolation. The other factor was that I wanted to be able to print large; 30 inch, perhaps even 40 inch images with good quality. When I recently purchased my GX1 I was also keen to ensure it would allow me to print large.

The GX1 is a 16Mpixel camera but it’s only the 4×3 format that gives an image this size. The 3×2 (similar format to my 5D) gives a smaller size and the 16×9 a smaller image still. To put this into context the 4×3 image would produce a 45Mb TIFF image, which is just short of the size required by the stock library but it’s not too far off and easily achieved with some interpolation. Print size was however the more important to me and out the camera the image is around 15” on its longest side when printed at 300dpi.

Now you are possibly reading this and thinking that the resolution is more than enough to create a 30” print given the viewing distance should be at least 3 feet and I would agree with you. I am however quite fussy (as are most photographers) and I want to look more closely at areas of my photographs and feel happy and confident that the image stands close scrutiny. Now you might think I am ignoring lens quality (which is true) but I know the 14-45 standard lens I use is more than capable of resolving sharp detail. No, what matters to me is the question am I satisfied when I look at the image closely when I print at 30 or even 40 inches.

To test this I resized my starting image (above) to 30 and 40 inches at 300 dpi using Genuine Fractals. I then extracted A4 sized sections from each image, sharpened and printed these on A4 Gloss paper ready to examine the results. If you want to know why I picked this image it’s because it has lots of fine detail. The glass as you can see from the images below has lots of fine straight, parallel lines on it that will show up any problems.


Image sample when viewed at 100%.

So the results? I’m not happy with the 40 inch print when viewed closely but it will be fine at normal viewing distance. The 30 inch print as show by the sample below is however is very good and you need to look very closely indeed to see the problem areas.


Image sample from 30 inch print scanned at 75ppi.

I do however know that I could achieve a good 40 inch print as I would simply reduce the resolution of the 30 inch print to 200dpi rather than 300dpi. I am also questioning the results of the Genuine Fractals software as I find it produces quite blocky results and this is what I can see in the 40inch print, but that’s another issue for another day.

Have I proved anything? Only that I am now satisfied that the GX1 is a really credible performer and fast becoming my camera of choice.
